Description

Level Up

A mountain bike built to raise your game and ignite a passion for the trail. Designed for the mountains and ready for anything.

Highlights

• Light and durable SmartForm C3 Alloy frame
• SR Suntour XCT suspension fork, 100mm travel
• Shimano 8-speed shifting w/double chainring crank / Shimano hydraulic disc brakes

Where it thrives

Low-impact trails, gravel roads, leisurely ride

What it’s built for

Handling, durability

Assembly Video on How to Assemble Cannondale Trail Bike

• As of September 2021, Cannondale does not include assembly tools inside bike box.  These tools are the responsibility of the mechanic or customer

SPECS

• Bottom Bracket – Cartridge, square taper
• Chain – KMC X8, 8-speed
• Crank – Prowheel, 36/22
• Front Derailleur – Shimano Altus, 34.9 clamp
• Rear Cogs – Sunrace, 11-34, 8-speed
• Rear Derailleur – Shimano Acera
• Shifters – Shimano M315 Rapidfire Plus, 8-speed
• Fork – SR Suntour XCT, 100mm, coil, 42mm offset (27.5″) 46mm offset (29″)
• Frame – SmartForm C3 Alloy, SAVE, 1-1/8″ headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
• Headset – Semi Integrated, 1-1/8″
• Front Hub – Shimano HBTX 505
• Rear Hub – Shimano FHTX505
• Rims – WTB SX19, 32h
• Spokes – Stainless Steel, 14g
• Tire Size – 2.25
• Tires – WTB Ranger Comp, 27.5/29 x 2.25″, DNA Compound
• Wheel Size – 29
• Brake Levers – Shimano MT200 hydraulic disc
• Brakes – Shimano MT200 hydraulic disc, 160/160mm RT10 rotors
• Grips – Cannondale Dual-Density
• Handlebar – Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
• Saddle – Cannondale Stage 3
• Seatpost – Cannondale 3, 6061 Alloy, 31.6 x 350/400mm
• Stem – 6061 Alloy, 31.8, 7°
• *Specifications subject to change without notice

• Mack Cycle recommends having your bike assembled by your local, authorized Cannondale retailer, who will charge an assembly fee.
